Vitara Specifications

Get the full specifications, features and dimensions of the Suzuki Vitara Range.
Find details of the Vitara, Turbo, Turbo ALLGRIP, Shadow and Turbo Shadow engine, capacity, safety & more.

Show differences

Show / Hide all

	Vitara Vitara MY23	Vitara	Vitara Vitara Turbo MY23	Vitara Vitara Turbo	Vitara Vitara Turbo ALLGRIP
Immobiliser	STD	STD	STD	STD	STD
Front airbags	STD	STD	STD	STD	STD
Side airbags	STD	STD	STD	STD	STD
Curtain airbags	STD	STD	STD	STD	STD
Knee airbag (driver)	STD	STD	STD	STD	STD
Anti-lock braking system (ABS)	STD	STD	STD	STD	STD
Electronic brakeforce distribution (EBD)	STD	STD	STD	STD	STD
Brake assist system (BAS)	STD	STD	STD	STD	STD
Vehicle stability control (ESP®)^	STD	STD	STD	STD	STD
Traction control	STD	STD	STD	STD	STD
Front seat belts	3-POINT ELR, WITH PRE-TENSIONERS, LOAD LIMITERS	3-POINT ELR, WITH PRE-TENSIONERS, LOAD LIMITERS	3-POINT ELR, WITH PRE-TENSIONERS, LOAD LIMITERS	3-POINT ELR, WITH PRE-TENSIONERS, LOAD LIMITERS	3-POINT ELR, WITH PRE-TENSIONERS, LOAD LIMITERS
Rear seat belts	3 x 3-POINT ELR	3 x 3-POINT ELR	3 x 3-POINT ELR	3 x 3-POINT ELR	3 x 3-POINT ELR
Child seat anchorage points	2 X ISOFIX, 3 X TETHER ANCHORAGES	2 X ISOFIX, 3 X TETHER ANCHORAGES	2 X ISOFIX, 3 X TETHER ANCHORAGES	2 X ISOFIX, 3 X TETHER ANCHORAGES	2 X ISOFIX, 3 X TETHER ANCHORAGES
Hill hold control Automatic	STD	STD	STD	STD	STD
Hill descent control	-	-	-	-	STD
Autonomous emergency braking	-	-	STD	STD	STD
Lane departure warning	-	-	STD	STD	STD
Weaving alert	-	-	STD	STD	STD
Blind spot monitoring	-	-	STD	STD	STD
Rear cross traffic alert	-	-	STD	STD	STD

Interior

	Vitara Vitara MY23	Vitara	Vitara Vitara Turbo MY23	Vitara Vitara Turbo	Vitara Vitara Turbo ALLGRIP
Steering wheel	LEATHER COVERED	LEATHER COVERED	LEATHER COVERED	LEATHER COVERED	LEATHER COVERED
Column adjustment	TILT AND TELESCOPIC	TILT AND TELESCOPIC	TILT AND TELESCOPIC	TILT AND TELESCOPIC	TILT AND TELESCOPIC
Cruise control	STD	STD	STD	STD	STD
Power windows	STD	STD	STD	STD	STD
Power door locks	STD	STD	STD	STD	STD
Remote controlled	STD	STD	STD	STD	STD
Keyless Entry and Start System	STD	STD	STD	STD	STD
Air conditioning	DIGITAL CLIMATE CONTROL	DIGITAL CLIMATE CONTROL	DIGITAL CLIMATE CONTROL	DIGITAL CLIMATE CONTROL	DIGITAL CLIMATE CONTROL
Pollen filter	STD	STD	STD	STD	STD
Information display
Digital clock	STD	STD	STD	STD	STD
Outside temperature gauge	STD	STD	STD	STD	STD
Fuel consumption gauge (instantaneous / average)	STD	STD	STD	STD	STD
Driving range	STD	STD	STD	STD	STD
Gear position indicator Automatic	STD	STD	STD	STD	STD
Seat upholstery	FABRIC WITH STITCHING	FABRIC WITH STITCHING	LEATHER ACCENTED WITH SUEDE INSERTS	LEATHER ACCENTED WITH SUEDE INSERTS	LEATHER ACCENTED WITH SUEDE INSERTS
Front seat height adjustment	DRIVER	DRIVER	DRIVER	DRIVER	DRIVER
Rear seats	60:40 SPLIT FOLDING	60:40 SPLIT FOLDING	60:40 SPLIT FOLDING	60:40 SPLIT FOLDING	60:40 SPLIT FOLDING
Head rests	FRONT X2, REAR X3	FRONT X2, REAR X3	FRONT X2, REAR X3	FRONT X2, REAR X3	FRONT X2, REAR X3
Front map light	STD	STD	STD	STD	STD
Centre cabin light	STD	STD	STD	STD	STD
Boot light	STD	STD	STD	STD	STD
Luggage area light	STD	STD	STD	STD	STD
Cup holders	FRONT X 2	FRONT X 2	FRONT X 2	FRONT X 2	FRONT X 2
Bottle holders	FRONT DOOR X2, REAR DOOR X2	FRONT DOOR X2, REAR DOOR X2	FRONT DOOR X2, REAR DOOR X2	FRONT DOOR X2, REAR DOOR X2	FRONT DOOR X2, REAR DOOR X2
12v power outlet	CENTRE-LOWER BOX	CENTRE-LOWER BOX	CENTRE-LOWER BOX	CENTRE-LOWER BOX	CENTRE-LOWER BOX
Luggage area cover	STD	STD	STD	STD	STD

Audio

	Vitara Vitara MY23	Vitara	Vitara Vitara Turbo MY23	Vitara Vitara Turbo	Vitara Vitara Turbo ALLGRIP
Speakers (number of)	SPEAKER X 4	SPEAKER X 4	SPEAKER X 4, TWEETER X 2	SPEAKER X 4, TWEETER X 2	SPEAKER X 4, TWEETER X 2
Steering wheel controls	STD	STD	STD	STD	STD
Touch screen	7-INCH	7-INCH	7-INCH	7-INCH	7-INCH
Voice command	STD	STD	STD	STD	STD
External devices connectivity	STD	STD	STD	STD	STD
Bluetooth® connectivity	STD	STD	STD	STD	STD

Exterior

	Vitara Vitara MY23	Vitara	Vitara Vitara Turbo MY23	Vitara Vitara Turbo	Vitara Vitara Turbo ALLGRIP
Headlights	HALOGEN	HALOGEN	LED	LED	LED
With dusk sensor	-	-	STD	STD	STD
Front fog lights	STD	STD	STD	STD	STD
Door mirrors	ELECTRICALLY ADJUSTABLE	ELECTRICALLY ADJUSTABLE	ELECTRICALLY ADJUSTABLE & FOLDING	ELECTRICALLY ADJUSTABLE & FOLDING	ELECTRICALLY ADJUSTABLE & FOLDING
Door mirrors - finish	Match colour of roof	Match colour of roof	Colour matched to roof	Colour matched to roof	Colour matched to roof
Built in turning indicator lights	-	-	STD	STD	STD
Door handles - finish	BODY COLOURED	BODY COLOURED	BODY COLOURED	BODY COLOURED	BODY COLOURED
Rear window washer and wiper	STD	STD	STD	STD	STD
Rear window wiper	STD	STD	STD	STD	STD
Windshield wipers with rain sensor	-	-	STD	STD	STD
Parking sensors	-	-	STD	STD	STD
Reversing Camera	STD	STD	STD	STD	STD
Sunroof	-	-	-	-	STD

Powertrain

	Vitara Vitara MY23	Vitara	Vitara Vitara Turbo MY23	Vitara Vitara Turbo	Vitara Vitara Turbo ALLGRIP
Engine type	1.6L with VVT	1.6L with VVT	1.4L Petrol BOOSTERJET	1.4L Petrol BOOSTERJET	1.4L Petrol BOOSTERJET
Displacement (cm3)	1586	1586	1373	1373	1373
Cylinders	4	4	4	4	4
Valves	16	16	16	16	16
Bore x stroke (mm)	78.0x83.0	78.0x83.0	73.0x82.0	73.0x82.0	73.0x82.0
Compression ratio	11	11	10	10	10
Variable valve timing / camshaft	VVT	VVT	VVT	VVT	VVT
Maximum power (kW @ rpm)	86/6,000	86/6,000	103/5,500	103/5,500	103/5,500
Maximum torque (Nm @ rpm)	156/4,400	156/4,400	220/1,500-4,000	220/1,500-4,000	220/1,500-4,000
Manual Transmission
Type	5 Speed Manual	5 Speed Manual	-	-	-
1st gear ratio	3.545	3.545	-	-	-
2nd gear ratio	1.904	1.904	-	-	-
3rd gear ratio	1.258	1.258	-	-	-
4th gear ratio	0.911	0.911	-	-	-
5th gear ratio	0.725	0.725	-	-	-
Reverse gear ratio	3.25	3.25	-	-	-
Final drive ratio	4.411	4.411	-	-	-
Automatic Transmission
Type	6 Speed Automatic	6 Speed Automatic	6 Speed Automatic	6 Speed Automatic	6 Speed Automatic
Paddle shifters	Paddle Shifters	Paddle Shifters	Paddle Shifters	Paddle Shifters	Paddle Shifters
1st gear ratio	4.667	4.667	4.044	4.044	4.044
2nd gear ratio	2.533	2.533	2.371	2.371	2.371
3rd gear ratio	1.556	1.556	1.556	1.556	1.556
4th gear ratio	1.135	1.135	1.159	1.159	1.159
5th gear ratio	0.859	0.859	0.852	0.852	0.852
6th gear ratio	0.686	0.686	0.672	0.672	0.672
Reverse gear ratio	3.394	3.394	3.193	3.193	3.193
Final drive ratio	3.502	3.502	3.502	3.502	3.502
All-wheel drive	-	-	-	-	ALLGRIP 4WD System
Fuel
Fuel Tank Capacity (L)	47	47	47	47	47
Consumption* (L / 100km) manual	5.8	5.8	-	-	-
Consumption* (L / 100km) automatic	6.0	6.0	5.9	5.9	6.2
CO2 emissions (g / km) manual	136	136	-	-	-
CO2 emissions (g / km) automatic	139	139	138	138	145

Chassis

	Vitara Vitara MY23	Vitara	Vitara Vitara Turbo MY23	Vitara Vitara Turbo	Vitara Vitara Turbo ALLGRIP
Steering	Rack & Pinion	Rack & Pinion	Rack & Pinion	Rack & Pinion	Rack & Pinion
Gross vehicle weight (kg)	1730	1730	1730	1730	1730
Spare wheel	Space Saver	Space Saver	Space Saver	Space Saver	Space Saver
Brakes
Front	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc
Rear	Disc	Disc	Disc	Disc	Disc
Suspension
Front	MacPherson strut with coil spring	MacPherson strut with coil spring	MacPherson strut with coil spring	MacPherson strut with coil spring	MacPherson strut with coil spring
Rear	Torsion beam with coil spring	Torsion beam with coil spring	Torsion beam with coil spring	Torsion beam with coil spring	Torsion beam with coil spring
Tyres & Wheels
Tyres (width / profile)	215/55	215/55	215/55	215/55	215/55
Wheel size	17"	17"	17"	17"	17"
Wheel type	Alloy	Alloy	Polished Alloy	Alloy	Polished Alloy
Weights
Kerb weight, minimum (kg) Manual	1165	1165	-	-	-
Kerb weight, minimum (kg) Automatic	1180	1180	1185	1185	1260
Towing Capacity
Braked (kg)	1200	1200	1200	1200	1200
Unbraked (kg)	400	400	400	400	400

Dimensions

	Vitara Vitara MY23	Vitara	Vitara Vitara Turbo MY23	Vitara Vitara Turbo	Vitara Vitara Turbo ALLGRIP
Overall length (mm)	4175	4175	4175	4175	4175
Overall width (mm)	1775	1775	1775	1775	1775
Overall height (mm)	1610	1610	1610	1610	1610
Wheelbase (mm)	2500	2500	2500	2500	2500
Kerb to kerb turning circle (m)	5.2	5.2	5.2	5.2	5.2
Ground clearance unladen (mm)	185	185	185	185	185
Number of doors	5	5	5	5	5
Seating capacity	5	5	5	5	5
Rear (mm)	1505	1505	1505	1505	1505
Track
Front (mm)	1535	1535	1535	1535	1535
Cargo capacity in litres
Rear seatback raised	375	375	375	375	375
Rear seatback folded	710	710	710	710	710
