Ignis Specifications

Show differences

Show / Hide all

	Ignis Ignis GL	Ignis Ignis GLX
Immobiliser	STD	STD
Front airbags	STD	STD
Side airbags	STD	STD
Curtain airbags	STD	STD
Anti-lock braking system (ABS)	STD	STD
Electronic brakeforce distribution (EBD)	STD	STD
Brake assist system (BAS)	STD	STD
Vehicle stability control (ESP®)^	STD	STD
Traction control	STD	STD
Front seat belts	3-POINT ELR WITH PRE TENSIONERS, LOAD LIMITERS	3-POINT ELR WITH PRE TENSIONERS, LOAD LIMITERS
Rear seat belts	3 X 3-POINT ELR	2 X 3-POINT ELR
Child seat anchorage points	2 X ISOFIX, 3 X TETHER ANCHORAGES	2 X ISOFIX, 3 X TETHER ANCHORAGES
Hill hold control Automatic	STD	STD

Interior

	Ignis Ignis GL	Ignis Ignis GLX
Steering wheel	LEATHER COVERED	LEATHER COVERED
Column adjustment	TILT	TILT
Cruise control	STD	STD
Power windows	STD	STD
Power door locks	STD	STD
Remote controlled	STD	STD
Keyless Entry and Start System	-	STD
Air conditioning	MANUAL	DIGITAL
Pollen filter	STD	STD
Information display
Digital clock	STD	STD
Outside temperature gauge	STD	STD
Fuel consumption gauge (instantaneous / average)	STD	STD
Driving range	STD	STD
Gear position indicator Automatic	STD	STD
Seat upholstery	FABRIC	FABRIC
Front seat height adjustment	DRIVER	DRIVER
Rear seats	60:40 SPLIT FOLDING	50:50 SPLIT FOLDING
Head rests	FRONT X2, REAR X 3	FRONT X2, REAR X2
Centre cabin light	STD	STD
Cup holders	FRONT X2, REAR X1	FRONT X2, REAR X1
Bottle holders	FRONT X2, REAR X2	FRONT X2, REAR X2
12v power outlet	STD	STD
Luggage area cover	STD	STD

Audio

	Ignis Ignis GL	Ignis Ignis GLX
Speakers (number of)	SPEAKER X 4	SPEAKER X 4, TWEETERS X 2
Steering wheel controls	STD	STD
Touch screen	7-INCH	7-INCH
Voice command	STD	STD
External devices connectivity	STD	STD
Bluetooth® connectivity	STD	STD

Exterior

Powertrain

	Ignis Ignis GL	Ignis Ignis GLX
Engine type	1.2L DUALJET	1.2L DUALJET
Displacement (cm3)	1242	1242
Cylinders	4	4
Valves	16	16
Bore x stroke (mm)	73.0 x 74.2	73.0 x 74.2
Compression ratio	12.5	12.5
Variable valve timing / camshaft	VVT	VVT
Maximum power (kW @ rpm)	66/6,000	66/6,000
Maximum torque (Nm @ rpm)	120/4,400	120/4,400
Manual Transmission
Type	5 SPEED MANUAL	-
1st gear ratio	3.545	-
2nd gear ratio	1.904	-
3rd gear ratio	1.24	-
4th gear ratio	0.914	-
5th gear ratio	0.717	-
Reverse gear ratio	3.272	-
Final drive ratio	4.294	-
Automatic Transmission
Type	CVT	CVT
Gear Ratio	4.006 ~ 0.550 (LOW: 4.006 ~ 1.001, HIGH: 2.200 ~ 0.550)	4.006 ~ 0.550 (LOW: 4.006 ~ 1.001, HIGH: 2.200 ~ 0.550)
Reverse gear ratio	3.771	3.771
Final drive ratio	3.757	3.757
Fuel
Fuel Tank Capacity (L)	32	32
Consumption* (L / 100km) manual	4.7	-
Consumption* (L / 100km) automatic	4.9	4.9
CO2 emissions (g / km) manual	107	-
CO2 emissions (g / km) automatic	114	114

Chassis

	Ignis Ignis GL	Ignis Ignis GLX
Steering	RACK & PINION	RACK & PINION
Gross vehicle weight (kg)	1330	1330
Spare wheel	SPACE SAVER	SPACE SAVER
Brakes
Front	VENTILATED DISC	VENTILATED DISC
Rear	DRUM, LEADING & TRAILING	DRUM, LEADING & TRAILING
Suspension
Front	MACPHERSON STRUT WITH COIL SPRING	MACPHERSON STRUT WITH COIL SPRING
Rear	TORSION BEAM WITH COIL SPRING	TORSION BEAM WITH COIL SPRING
Tyres & Wheels
Tyres (width / profile)	175/65	175/60
Wheel size	15"	16"
Wheel type	STEEL	ALLOY
Weights
Kerb weight, minimum (kg) Manual	820	820
Kerb weight, minimum (kg) Automatic	865	865

Dimensions

	Ignis Ignis GL	Ignis Ignis GLX
Overall length (mm)	3700	3700
Overall width (mm)	1660	1660
Overall height (mm)	1595	1595
Wheelbase (mm)	2435	2435
Kerb to kerb turning circle (m)	9.4	9.4
Ground clearance unladen (mm)	180	180
Approach angle (o)	20	20
Ramp breakover angle (o)	18	18
Departure angle (o)	38	38
Number of doors	5	5
Seating capacity	5	4
Rear (mm)	1470	1470
Track
Front (mm)	1460	1460
Cargo capacity in litres
Rear seatback raised	271	264
Rear seatback folded	1101	1104
Rear seat down; to lower window	505	516
